4 Core Armoured Electrical Cable Low Voltage 0.6 /1KV 4Cx120mm Double Steel Tape

Produk

kabel obor las

Hubungi kami

Mr. Aric

atwood.lee@hold-one.com

86-- 18724796885

Hubungi Sekarang

4 Core Armoured Electrical Cable Low Voltage 0.6 /1KV 4Cx120mm Double Steel Tape

Jumlah Pesanan Minimum:	300m
harga:	USD 0.78-2.77/M
kemasan standar:	Drum kayu
Periode pengiriman:	7 hari
metode pembayaran:	L/C, T/T
Kapasitas Pasokan:	689352 KM / minggu

Rincian Informasi

Deskripsi produk

Informasi Rinci

Tempat asal

Cina

Nama merek

QINGDAO YICABLE CABLE

Sertifikasi

ISO,CE,IEC,TUV,KEMA

selubung batin:

PVC

Konduktor:

Kawat Tembaga Terdampar.

Jaket:

PVC

Sampel:

Bebas

Lapis Baja:

Kawat Baja Bulat.

uji Tegangan:

3.5KV

Jaket warna:

Hitam

Menyoroti:

armored electrical wire

armored cable wiring

Deskripsi produk

Four Core Low Voltage 0.6/1KV 4Cx120mm2 Double Steel Tape Armoured Electrical Cable.

Construction

Conductor	Compact Stranded Copper Conductor, Class 2 as per IEC 60228
Conductor	Circular solid Copper Conductor, Class 1 as per IEC 60228
Insulation	XLPE(Cross-linked polyethylene)
Filler	PP Filler
Wrapping Tape	Non woven
Inner Covering	Extruded PVC
Armour	Steel Wire
Overall Sheath	Termite Resistant PVC

Applications

Used for power transmission and distribution line with voltage rated at 35kV and below.Compared with PVC Insulated Power Cable, xlpe power cable boasts not only characteristics of excellent electricity, mechanism,

heat and aging-resistant, environment stress-resistant and chemical corrosion-resistant, but also simple

structure, light weight, no restriction by laying drop, and high temperature allowance for long-term working.

Standards

International: IEC 60502-2, IEC 60228

China: GB/T 12706.2-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage: 0.6/1kV

Maximum Conductor Temperature: under normal (90°C), emergency (130°C) or short circuit no more than 5 s (250°C) conditions.

Min. Ambient Temp. 0°C, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single-core non-armoured cables

15 x cable O.D for single-core armoured cables

15 x cable O.D for multi-core non-armoured cables

12 x cable O.D for multi-core armoured cables

Specifications

Nom. Cross-section of conductor

Strands

No./Dia. Of Conductor

Insulation Thickness

Inner Covering Thickness

Dia. Of Armor Wire

Sheath Thickness

Approx. O.D.

Approx.

Weight

Max. D.C Resistance of Conductor (20 ℃)

Testing Voltage A.C

Current Rating

mm²

pc/mm

(mm)

kg/km

Ω /km

kV/5min

In air (A)

In soil(A)

4 × 4	7/0.85	0.7	1.0	0.9	1.8	18.0	699	4.61	3.5	34	45
4 × 6	7/1.04	0.7	1.0	1.25	1.8	19.0	820	3.08	3.5	43	57
4 × 10	7/1.38	0.7	1.0	1.25	1.8	22.0	1233	1.83	3.5	60	77
4 × 16	7/1.78	0.7	1.0	1.6	1.8	24.5	1550	1.15	3.5	83	105
4 × 25	7/2.14	0.9	1.0	1.6	1.8	29.2	2036	0.727	3.5	105	125
4 × 35	7/2.52	0.9	1.0	2.0	1.9	32.5	2501	0.524	3.5	125	155
4 × 50	10/2.52	1.0	1.0	2.0	2.0	33.0	3064	0.387	3.5	160	185
4 × 70	14/2.52	1.1	1.0	2.0	2.1	37.0	3974	0.268	3.5	200	225
4 × 95	19/2.52	1.1	1.2	2.0	2.3	43.0	5032	0.193	3.5	245	270
4 × 120	24/2.52	1.2	1.2	2.5	2.5	45.0	6327	0.153	3.5	285	310
4 × 150	30/2.52	1.4	1.4	2.5	2.7	51.0	7765	0.124	3.5	325	345
4 × 185	37/2.52	1.6	1.4	2.5	2.8	56.0	9205	0.0991	3.5	375	390
4 × 240	48/2.52	1.7	1.4	2.5	3.0	62.0	11444	0.0754	3.5	440	450
4 × 300	61/2.52	1.8	1.6	2.5	3.2	67.0	13830	0.0601	3.5	505	515
4 × 400	61/2.97	2.0	1.6	3.15	3.5	74.0	19673	0.0470	3.5	570	575
