1.5 mm2 2.5 mm2 Low Smoke Zero Halogen Cable Fire Resistive Electrical Cable IEC60332

1.5 mm2 2.5 mm2 Low Smoke Zero Halogen Cable Fire Resistive Electrical Cable IEC60332

Jumlah Pesanan Minimum: 1000m
harga: 0.38-10.6
kemasan standar: Kayu drum atau kasus
Periode pengiriman: Sebagai per schedual
metode pembayaran: L/C, T/T
Kapasitas Pasokan: 50KM/bulan
Informasi Rinci
Tempat asal
Cina
Nama merek
QINGDAO YICABLE CABLE
Sertifikasi
CE/KEMA
Suhu bekerja:
90 ℃
Tipe:
Menurunkan tegangan 450 70V
warna isolasi:
Oranye atau opsional
Fungsi:
Tahan Api
Sampel:
1-1.5m
Aplikasi:
bangunan
Menyoroti:

low smoke zero halogen wire

,

lszh power cable

Deskripsi produk

1.5mm2 2.5mm2 Copper Conductor Fire Resistive Electrical Cable IEC60332

Specifications

Fire Resistive Power Cable, Fire Rated Power Cable, Flame Retardant Power Cable

Specifications:


Conductor : Plain Annealed, Stranded Circular Non – Compacted or Circular Compacted or Shaped Copper
Fire Barrier : Mica Tape
Insulation : FR-PVC
Sheath : None or FR-PVC
Insulation Colour :

2C – Brown & Blue

3C – Brown, Black & Grey

4C – Brown, Black, Grey & Blue

2C+E – Brown, Blue + Green/Yellow

3C+E – Brown, Black, Grey + Green/Yellow

4C+E – Brown, Black, Grey, Blue + Green/Yellow

5C & above – White Cores Printed With Number

Sheath Colour : As Request



Note:
1. The models also contain fire-resistant type of low voltage power cable.
2. When signing the contract, the fire resistant type must be specified. For example, if type A is preferred, please add "A" to the end of "ZR", forming "ZRA", and A is usually used in places where the fire resistant property is highly required. B and C follow the same rule. In addition, if there is no letter after "ZR", the cable will be produced following "ZRC".

Quality Assurance:

With Yiteng, all cables are produced by strict inspection and testing:

1). Raw Material: Copper, Aluminium, PVC, PE and XLPE granules and all other materials for producing cables are all inspected carefully automatically. Only the qualified will be applied into cable production, the disqualified will be rejected.



2). Production Procedure: Cables are produced by advanced cable production machines.



3). Testing: Cables will not be packed until they are tested totally qualified. Cable Testing Machines includes Online Core Shift Detection Device, Tension Tester, Aging Test Chamber, Experimental Apparatus of Combustion, Insulation Resistance Tester and etc…



1.5 mm2 2.5 mm2 Low Smoke Zero Halogen Cable Fire Resistive Electrical Cable IEC60332 0

Produk
rincian produk
1.5 mm2 2.5 mm2 Low Smoke Zero Halogen Cable Fire Resistive Electrical Cable IEC60332
Jumlah Pesanan Minimum: 1000m
harga: 0.38-10.6
kemasan standar: Kayu drum atau kasus
Periode pengiriman: Sebagai per schedual
metode pembayaran: L/C, T/T
Kapasitas Pasokan: 50KM/bulan
Informasi Rinci
Tempat asal
Cina
Nama merek
QINGDAO YICABLE CABLE
Sertifikasi
CE/KEMA
Suhu bekerja:
90 ℃
Tipe:
Menurunkan tegangan 450 70V
warna isolasi:
Oranye atau opsional
Fungsi:
Tahan Api
Sampel:
1-1.5m
Aplikasi:
bangunan
Kuantitas min Order:
1000m
Harga:
0.38-10.6
Kemasan rincian:
Kayu drum atau kasus
Waktu pengiriman:
Sebagai per schedual
Syarat-syarat pembayaran:
L/C, T/T
Menyediakan kemampuan:
50KM/bulan
Menyoroti

low smoke zero halogen wire

,

lszh power cable

Deskripsi produk

1.5mm2 2.5mm2 Copper Conductor Fire Resistive Electrical Cable IEC60332

Specifications

Fire Resistive Power Cable, Fire Rated Power Cable, Flame Retardant Power Cable

Specifications:


Conductor : Plain Annealed, Stranded Circular Non – Compacted or Circular Compacted or Shaped Copper
Fire Barrier : Mica Tape
Insulation : FR-PVC
Sheath : None or FR-PVC
Insulation Colour :

2C – Brown & Blue

3C – Brown, Black & Grey

4C – Brown, Black, Grey & Blue

2C+E – Brown, Blue + Green/Yellow

3C+E – Brown, Black, Grey + Green/Yellow

4C+E – Brown, Black, Grey, Blue + Green/Yellow

5C & above – White Cores Printed With Number

Sheath Colour : As Request



Note:
1. The models also contain fire-resistant type of low voltage power cable.
2. When signing the contract, the fire resistant type must be specified. For example, if type A is preferred, please add "A" to the end of "ZR", forming "ZRA", and A is usually used in places where the fire resistant property is highly required. B and C follow the same rule. In addition, if there is no letter after "ZR", the cable will be produced following "ZRC".

Quality Assurance:

With Yiteng, all cables are produced by strict inspection and testing:

1). Raw Material: Copper, Aluminium, PVC, PE and XLPE granules and all other materials for producing cables are all inspected carefully automatically. Only the qualified will be applied into cable production, the disqualified will be rejected.



2). Production Procedure: Cables are produced by advanced cable production machines.



3). Testing: Cables will not be packed until they are tested totally qualified. Cable Testing Machines includes Online Core Shift Detection Device, Tension Tester, Aging Test Chamber, Experimental Apparatus of Combustion, Insulation Resistance Tester and etc…



1.5 mm2 2.5 mm2 Low Smoke Zero Halogen Cable Fire Resistive Electrical Cable IEC60332 0
