XLPE Insulated Cable

Jumlah Pesanan Minimum:	100meter
harga:	USD 3.76-7.68/M
kemasan standar:	Drum kayu
Periode pengiriman:	7 hari
metode pembayaran:	L / C, T / T,
Kapasitas Pasokan:	436970KM / Minggu

Rincian Informasi

Deskripsi produk

Informasi Rinci

Tempat asal

Cina

Nama merek

QINGDAO YICABLE CABLE

Sertifikasi

KEMA/CE/ISO/TUV/RoSH

Layar bahan:

Tape tembaga

Tegangan pengenal:

6.35 / 11KV

Jaket:

PVC

Sampel:

Bebas

uji Tegangan:

3.5KV

Suhu operasi:

90 derajat

kabel Mark:

Pencetakan atau embossing

Pasar utama:

Asia, Afrika

Menyoroti:

xlpe power cable

cross linked polyethylene cable

Deskripsi produk

Three Core Copper Conductor XLPE Insulated Medium Voltage 11kV Power Cable

Constructions

Conductor : Compact stranded copper conductor, Cl.2 as per IEC 60228

Conductor Screen: Semi-conductor

Insulation : XLPE(cross-linked polyethylene) rated at 90 OC

Insulation Screen: Semi-conductor

Screen : Copper tape

Sheath : PVC or FR-PVC type ST2 to IEC 60502, black

Note: Insulation color as per standards or customer requirement

Applications

For laying indoors and outdoors. Able to bear certain traction during installation, but not external mechanical forces. Laying single core cable in magnetic ducts is not allowed.

Standards

International: IEC 60502, IEC 60228

China: GB/T 12706.1-2008

Other standards such as BS,DIN and ICEA upon request

Technical data

Rated voltage:6/10kV

Maximum Conductor Temperature: under normal (90^OC), emergency (130^OC) or short circuit no more than 5 s (250℃) conditions.

Min. Ambient Temp. 0^OC, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single core

15 x cable O.D for multi core

Certificates

CE, RoHS, CCC, KEMA and more others at request

Technical Specifications

Nom. Cross-section of conductor	Strands No./Dia. Of Conductor	Insulation Thickness	Sheath Thickness	Approx. O.D.	Approx.Weight	Max. D.C Resistance of Conductor (20 ℃)	Testing Voltage A.C	Current Rating
mm²	pc/mm	mm	mm	(mm)	kg/km	Ω /km	kV/5min	In air (A)	In soil(A)
1 × 25	7/2.14	4.5	1.8	23.0	598	0.727	30.5	140	150
1 × 35	7/2.52	4.5	1.8	24.0	680	0.524	30.5	175	180
1 × 50	10/2.52	4.5	1.9	25.0	804	0.387	30.5	205	215
1 × 70	14/2.52	4.5	1.9	27.0	984	0.268	30.5	260	265
1 × 95	19/2.52	4.5	2	29.0	1201	0.193	30.5	315	315
1 × 120	24/2.52	4.5	2	30.0	1490	0.153	30.5	365	360
1 × 150	30/2.52	4.5	2.1	32.0	1765	0.124	30.5	415	405
1 × 185	37/2.52	4.5	2.1	34.0	2091	0.0991	30.5	475	455
1 × 240	48/2.52	4.5	2.2	36.0	3034	0.0754	30.5	565	530
1 × 300	61/2.52	4.5	2.4	39.0	3672	0.0601	30.5	645	595
1 × 400	61/2.97	4.5	2.4	42.0	4646	0.0470	30.5	750	680
1 × 500	61/3.23	4.5	2.5	45.0	5651	0.0366	30.5	865	765
1 × 630	61/3.50	4.5	2.5	50.0	7154	0.0283	30.5	990	860
1 × 800	91/3.20	4.5	2.7	55.0	8750	0.0221	30.5	1140	950
1 × 1000	91/3.75	4.5	2.9	59.0	10727	0.0176	30.5	1250	1040
3 × 25	7/2.14	4.5	2.4	46.0	2573	0.727	30.5	120	125
3 × 35	7/2.52	4.5	2.6	48.0	2985	0.524	30.5	145	155
3 × 50	10/2.52	4.5	2.7	51.0	3529	0.387	30.5	175	180
3 × 70	14/2.52	4.5	2.8	55.0	4197	0.268	30.5	220	220
3 × 95	19/2.52	4.5	2.9	58.0	5230	0.193	30.5	265	265
3 × 120	24/2.52	4.5	3.0	61.0	6120	0.153	30.5	305	300
3 × 150	30/2.52	4.5	3.1	64.0	7207	0.124	30.5	350	340
3 × 185	37/2.52	4.5	3.2	68.0	8378	0.0991	30.5	395	380
3 × 240	48/2.52	4.5	3.4	73.0	10177	0.0754	30.5	470	435
3 × 300	61/2.52	4.5	3.5	77.0	12159	0.0601	30.5	535	485
3 × 400	61/2.97	4.5	3.8	86.0	15641	0.0470	30.5	610	520

Ordering Advice

Rated Voltage

Application Standard: IEC/BS/UL/GB

Number of Cores

Conductor Size & Construction

Type of Insulation

Armored or unarmored. If armor, the armor type & material

The Requirement of Sheath

Length of Cable & Packing Requirement
